JIS-L1018、L1096、ASTM-D747

The bending stiffness refered to hear means the apprent elastic modulus obtaied from the cantilever test specimen and the bending angle.

Load scale

0～100％（Unit 1％）

Load position

1・1/2", 3" from rotating shaft

Angle scale

0～90°（Unit 1°）

Grip rotaing speed

60°/min

Specimen

25x50mm

Power source

AC220V 1-phase 3A 50/60Hz

Dimensions/Weight

W350xD230xH460mm・20kg
